Standard Configurations:

• Ultrasound scanner with 15“ LCD monitor
• Image workstation with 21.5“ LCD monitor
• 3.5MHz Convex Probe: 1pc

Standard configurations:

• 6.5MHz Trans-vaginal Probe: 1pc
• 7.5 MHz Linear Probe
• Video printer and Ink-jet printer

• Specifications
• Ultrasound scanner with 15" LCD monitor.
• Detecting depth: ≥220mm
• Display mode: B, B+B, B+M, M, 4B.
• Gray Scale: 256.
• Image amplification: x1.0, x 1.2, x1.5, x2.0
• Local zoom: 2 times.
• Electronic focusing: 4 focuses combination randomly.
• Measurement: distance, circumference, area, heart rate, gestational week, fetal weight etc
• Annotation: time, date, ID, age, sex, detecting depth, probe type, focus, frame correlation etc.
• English-Chinese conversion.
• Cine-loop:341
• Image load/storage: 32
• Obstetric table: BPD, CRL, GS, FL, AC, HC, FW, EDD.
• Body marks: 40 types
• Power Supply: 100V-130V/220V-240V. 50/60Hz.

2. Imaging workstation specification:

• Main board: Acer
• CPU: I N TEL G3900
• EMS memory: 4G
• Hard disk: 1T
• Monitor: 21.S"LCD
