Product name: Full Digital Portable Ultrasound Scanner
  • Packaging Details:
  • Delivery Time:
DETAILED

Main feature:

  • Monitor: 12.1" high solution LCD.
  • Back-Iit silica gel keyboard, photoelectric trackball and encoder, easy to operate.
  • Abundant software : Abdomen, Obstetric, Gynecology, Cardiac, Urological and other part measurement.
  • 28 grades depth adjustment under full visual field, maximum display depth is 240mm.
  • Puncture guiding function, optional puncture probe, realizing ultrasound intervention requirement.
  • 128 frames permanent storage, 256 frames cine loop.
  • Various output ports can be support images and reports printing directly ..
  • DICOM3.0 network port, easily real izes network transmission function





Technical Specifications:

  • Display depth (mm): 240 (max),16 levels adjustable.
  • Monitor size:12 inch.
  • Display mode: B、B + B、B + M 、M 、4B.
  • Image gray scale:256 level.
  • Cine loop: 809 frame (Max).
  • Image storage: 32 frames.
  • Scan angle: Adjustable.
  • Scan depth: 40mm-240mm
  • Acoustic power: 2 steps.
  • Dynamic range: 100dB-130dB
  • Probe elements : 96.
  • Image flip: Up/down, left/right, black/white.
  • Focus position: Adjustable.

  • Focal space: 5 level.
  • Measurement: Distance, circumference, area, volume, heart rate, GA, FW, EDD.
  • Notation: Date, time, name, sex, age, doctor, hospital name. Full screen words edit
  • Output report: 2 type.
  • Posture mark : ≥40.
  • Video output: PAL-D, VGA.
  • Machine dimension (mm): 320*165*290
  • Power Supply: AV220V±22V. 50MHz±1MHz



    Standard Configuration:

  • Scanner Body: 1pc
  • 3.5Mhz Convex Probe: 1pc
  • Charger with a Set of wires: 1set
  • Bottle of USG gel: 1pc
  • User Manual: 1pc


    Optional:

  • Scanner Body: 1pc
  • 3.5Mhz Convex Probe: 1pc
  • Charger with a Set of wires: 1set
  • Bottle of USG gel: 1pc
  • User Manual: 1pc
